RoboCasa365

Kitchen scenes, objects, and tasks in RoboCasa365. Source: RoboCasa365 project.

Run kitchen manipulation tasks with RPent in RoboCasa365, then reproduce Target50 experiments. This integration uses the PandaOmron mobile manipulator and the RLDX-1 action model; its CLI name is robocasa.

Overview

Check the model, task, and runtime requirements before following the installation and run steps.

Action Models

RLDX-1

Planners

api, claude_code, codex

Tasks

Target50 kitchen tasks

Hardware

Linux, NVIDIA GPU; Python 3.10; CUDA and EGL.

Tasks

Target50 covers the following categories. The reproduction section lists the complete task/seed matrix and run limits.

Category	Tasks	Scope
Atomic	18	Individual kitchen operations.
Composite-Seen	16	Composite tasks in seen categories.
Composite-Unseen	16	Composite tasks in unseen categories.

Observation and Action

The table distinguishes planner tools, model inputs, and the environment’s success criterion.

Item	Description
Observation	Camera views, depth/world coordinates, and mobile-base, end-effector, and gripper state. RLDX-1 receives three camera histories plus state and task text.
Action	The planner calls rldx_skill and motion primitives. RLDX-1 predicts end-effector, gripper, base-motion, and control-mode commands.
Reward / success	Evaluate success using the environment’s _check_success() result exposed as state.success.
Task prompt	Use the current environment’s complete task_language; historical memory does not replace it.

Installation and Resources

Use Linux, an NVIDIA GPU, a working CUDA/EGL setup, git, and uv. If you already have the repository, enter it and start at environment creation.

RLDX-1 requires Python 3.10. Create a dedicated environment and install the complete RoboCasa365 stack with .[robocasa]:

git clone https://github.com/RLinf/RPent.git
cd RPent
uv venv --python 3.10 .venv-robocasa
source .venv-robocasa/bin/activate

First install a matching CUDA-enabled PyTorch and torchvision pair using the PyTorch installation selector for your GPU, driver and Python version. Run the selected command in this environment (use uv pip in place of pip). The RLDX dependency requires Torch >= 2.7 and torchvision >= 0.22; choose a mutually compatible pair, not two independent versions. Then install RPent:

uv pip install -e ".[robocasa]" \
   --constraint robots/robocasa/eval/target50-constraints.txt
uv pip check

The constraints file pins compatibility-sensitive Target50 dependencies. The robocasa extra installs the rpent branches of RoboCasa, RLDX, and Robosuite. Do not also install rlinf-robocasa365, which provides the same import package.

Choose Torch, torchvision, and CUDA for your machine. The reference run used Torch 2.7.0, torchvision 0.22.0, and CUDA 12.6. Record resolved dependencies and Git revisions for every reproduction because branches can advance:

uv pip freeze > installed-requirements.txt
git rev-parse HEAD > rpent-revision.txt

flash-attn is optional; RLDX-1 uses PyTorch SDPA when it is absent. If needed, follow the FlashAttention instructions to select a compatible build.

Post-install setup

Download the kitchen assets (~10 GB) outside site-packages so they survive reinstalls. Target50 does not use RoboCasa dataset or teleop macros, so skip the optional private-macros setup:

robocasa-download-assets --assets-path ~/.robocasa/assets --no-macros -y

It prints the environment variable to export afterwards; add it to the shell that launches rpent:

export ROBOCASA_ASSETS_PATH=~/.robocasa/assets

The installer supplies downloaded collections and bundled scene files. Add --skip-existing on subsequent runs to check existing downloads. See troubleshooting below for resource conflicts, disk space, and camera errors.

RLDX-1 checkpoint

The --vla-model-path flag on the run commands below expects a local path to the RLDX-1-FT-RC365 checkpoint (the RoboCasa365 fine-tune). Download it from HuggingFace:

hf download RLWRLD/RLDX-1-FT-RC365 \
   --revision 587e9ecdcc5e7184fcc17f58713908edff5af041 \
   --local-dir ./checkpoints/rldx-1-ft-rc365

If the download is slow, use the HF mirror:

HF_ENDPOINT=https://hf-mirror.com hf download RLWRLD/RLDX-1-FT-RC365 \
   --revision 587e9ecdcc5e7184fcc17f58713908edff5af041 \
   --local-dir ./checkpoints/rldx-1-ft-rc365

RLDX-1 backbone support files

The FT checkpoint contains the weights but also references RLWRLD/RLDX-1-VLM for architecture, processor and tokenizer metadata. Target50 freezes revision 4b9f870d1287e0d38d7eb1445e6d8c60afe66dd7: 15 non-weight files, about 16.4 MB including documentation and images. Download these into the same cache used when launching RPent:

export HF_HOME="$PWD/.cache/huggingface"
export HF_HUB_CACHE="$HF_HOME/hub"
hf download RLWRLD/RLDX-1-VLM \
   --revision 4b9f870d1287e0d38d7eb1445e6d8c60afe66dd7 \
   --include "*.json" "*.txt" "*.jinja" "*.md" "*.png" ".gitattributes" \
   --exclude "*.safetensors.index.json"

No additional base weights are required. Keep these cache variables in the launch shell; do not shadow them with an empty TRANSFORMERS_CACHE. The RoboCasa VLA worker automatically uses this same support revision for both ordinary and Target50 runs, including separately started RPent VLA servers. There is no extra revision flag or manual cache-ref edit. The pin applies only to backbone metadata, not the weights selected by --vla-model-path. Model and asset licenses apply separately from RPent’s code license.

Run a Task

Configure your model service with Planners and Model Services and check it using rpent-check-llm. Run OpenDrawer with seed 1:

rpent --robot robocasa \
      --task-name OpenDrawer \
      --split target \
      --seed 1 \
      --vla-model-path ./checkpoints/rldx-1-ft-rc365 \
      --planner claude_code \
      --model claude-opus-4-8

RoboCasa does not select a planner implementation; the api, claude_code, and codex planners can run this robot. See Planners and Model Services for configuration.

View Results

Task success comes from the environment’s _check_success() result, exposed as state.success. The planner’s finish status ends its conversation and is not an evaluation label. Inspect result.json, transcript_*.json, and run.log in the output directory; service startup errors are in env_server.log and vla_server.log.

Use --dashboard to watch cameras and planner output; see Dashboard for the shared workflow.

Task Memory

Select automatic synchronization with --memory-profile hf (the evaluation default). Before a run using this profile, RPent’s shared memory manager synchronizes the robocasa/** subtree from the RLinf/RPent-memory dataset into memory/robocasa. An online ordinary run therefore requires no separate memory download. The current task may use only these task-matched files under results/:

memory/robocasa/results/<Task>_s0.json
memory/robocasa/results/recipe_<Task>_s0.jsonl
memory/robocasa/results/<Task>.md  # optional

The final published corpus contains 43 audit JSON files, 43 recipe JSONL files, and 25 task Markdown files, for 111 files in total and no global memory. The JSON/JSONL pair contains reviewed seed-0 evidence. The optional Markdown file contains task-specific exploration memory and may summarize multiple attempts; all 16 Composite-Seen and 9 Composite-Unseen tasks provide one. The prompt requires the planner to read every current-task file that exists before acting. RPent makes those files available through read_text_file but does not inject their contents into the prompt.

When using the published HF memory above, the planner uses neither global memory nor another task’s memory. Seven Composite-Unseen tasks have no task memory and remain in the evaluation: HeatKebabSandwich, PanTransfer, PortionHotDogs, SeparateFreezerRack, WaffleReheat, WashFruitColander, and WeighIngredients. They continue from live observations. Memory is strategy evidence; historical coordinates, poses, pixels, and subtask prompts must not replace current localization or the live task language.

Exploration Mode

Add --explore to let the planner retry a task across fresh episodes and write local memory. As with LIBERO, one run allows up to three planner sessions with at most five attempts per session by default:

rpent --robot robocasa --task-name OpenDrawer --split target --seed 0 \
  --vla-model-path /path/to/rldx \
  --planner codex --reasoning-effort high --planner-timeout-s 7200 \
  --explore --explore-sessions 3 --explore-attempts-per-session 5 \
  --memory-dir /path/to/robocasa-memory

reset uses the environment’s ordinary episode reset. The runner exports only the winning commands after the final reset. Exploration memory is written to the current local inbox. Drafts are merged when the run completes normally without an agent execution error. Pass --no-auto-merge-memory to disable automatic merging. The exploration prompt is in robots/robocasa/prompts/explore.py and covers mobile-base use, task_progress, RLDX continuity, and failed-attempt notes.

Experiment Reproduction (Target50)

robots/robocasa/eval/target50.json is the canonical manifest for reproducing Harness VLA on RoboCasa Target50. It freezes the target environment split, HF resource revisions, memory scope, task and seed matrix, cell time limits, success source, and retry policy. Each cell is one task/seed combination. Its protocol ID is robocasa-harness-vla-v1. Source dependencies follow the recorded rpent branches and must be recorded at their resolved revisions for each run:

RoboCasa Target50 matrix

Split	Tasks	Seed range per task	Cell timeout	Cells
Atomic	18	1–10	1800 s	180
Composite-Seen	16	1–5	3600 s	80
Composite-Unseen	16	1–5	3600 s	80
Total	50			340

The tasks split into three groups:

• Atomic (18) — single-primitive articulation and pick-place tasks: CloseBlenderLid, CloseFridge, CloseToasterOvenDoor, CoffeeSetupMug, NavigateKitchen, OpenCabinet, OpenDrawer, OpenStandMixerHead, PickPlaceCounterToCabinet, PickPlaceCounterToStove, PickPlaceDrawerToCounter, PickPlaceSinkToCounter, PickPlaceToasterToCounter, SlideDishwasherRack, TurnOffStove, TurnOnElectricKettle, TurnOnMicrowave, TurnOnSinkFaucet.

• Composite seen (16) — multi-step tasks on kitchen layouts seen during training: ScrubCuttingBoard, StackBowlsCabinet, WashLettuce, RinseSinkBasin, PreSoakPan, StirVegetables, LoadDishwasher, SteamInMicrowave, SetUpCuttingStation, GetToastedBread, DeliverStraw, KettleBoiling, PrepareCoffee, StoreLeftoversInBowl, SearingMeat, PackIdenticalLunches.

• Composite unseen (16) — multi-step tasks on layouts not seen during training (generalization eval): ArrangeBreadBasket, ArrangeTea, BreadSelection, CategorizeCondiments, CuttingToolSelection, GarnishPancake, GatherTableware, HeatKebabSandwich, MakeIceLemonade, PanTransfer, PortionHotDogs, RecycleBottlesByType, SeparateFreezerRack, WaffleReheat, WashFruitColander, WeighIngredients.

Pass any of these to --task-name. The full RoboCasa catalog is larger; see the RoboCasa upstream.

Ordinary runs with the HF profile synchronize Hugging Face main. Formal Target50 runs use the immutable memory snapshot 551fc3157b3e56b40a3d3a3b4c7ff81721ebe89b:

hf download RLinf/RPent-memory \
   --repo-type dataset \
   --revision 551fc3157b3e56b40a3d3a3b4c7ff81721ebe89b \
   --include "robocasa/**" \
   --local-dir ./target50-memory

For Target50, first download the fixed resources above, then invoke one ordinary command for each manifest cell. The Codex reference profile is gpt-5.5, xhigh, and max_turns=100; RoboCasa itself remains planner-agnostic. For the scene identity, use the ordinary --seed argument and do not set RLDX_RESET_SEED. Ordinary RoboCasa uses max_chunks=70; Target50 alone overrides it to 40. Freeze the Target50 RLDX execution values first:

export RLDX_MAX_CHUNKS=40
export RLDX_SETTLE_PATIENCE=999
export RLDX_ACTION_STEPS_PER_CHUNK=8
unset RLDX_RESET_SEED

The first OpenDrawer Atomic cell is:

rpent --robot robocasa \
      --task-name OpenDrawer --split target --seed 1 \
      --vla-model-path ./checkpoints/rldx-1-ft-rc365 --cuda-device 0 \
      --planner codex --model gpt-5.5 --reasoning-effort xhigh \
      --max-turns 100 --planner-timeout-s 1800 \
      --memory-profile local \
      --memory-dir ./target50-memory/robocasa \
      --output-dir ./runs/target50/atomic/OpenDrawer_s1

Use --planner-timeout-s 3600 for either composite split. Execute Atomic, Composite-Seen, and Composite-Unseen in that order. A cell succeeds only when the final recorded environment state has state.success=true; the planner’s finish(status=...) argument is not an evaluation label. Valid task failures and planner timeouts are not retried. Retry an infrastructure failure only when no valid environment result was produced for that cell.

Every completed command atomically writes <output-dir>/result.json using the final environment state.success. The record includes the effective protocol values but omits provider errors and credentials. Once all cells are present under <results-root>/<manifest-split>/<Task>_s<seed>/result.json, validate the fixed denominator and print the task-weighted score with:

python -m robots.robocasa.eval.validate_target50 ./runs/target50

Published Target50 Results

The published Codex reproduction contains all 340 cells and reports the following task-level aggregates:

Codex Target50 reproduction

Split	Successful cells	Success rate	Harness VLA reference
Atomic	163/180	90.56%	165/180 (91.67%)
Composite-Seen	49/80	61.25%	45/80 (56.25%)
Composite-Unseen	12/80	15.00%	11/80 (13.75%)
Overall (task-weighted)	N/A	57.00%	55.40%

The complete per-task table contains the success count and accuracy for every task. The published record is task-level aggregate data; it does not include per-seed traces, raw trajectories, or failure classifications and therefore is not a per-cell audit artifact.

Environment Checks

After installing RoboCasa and its assets, run the opt-in environment smoke suite to check simulator installation and interfaces. It requires no planner credentials or VLA checkpoint:

uv pip install pytest pytest-timeout
RPENT_RUN_ROBOCASA_INTEGRATION=1 \
   pytest tests/integration_tests/robots/robocasa/test_target50_runtime_smoke.py -v

The four cases cover OpenDrawer, NavigateKitchen, and PickPlaceCounterToCabinet at seed 1, plus mobile-camera movement. Task checks verify construction/reset, 12D actions, operation cameras, navigation RGB-D/world map, the success predicate, and clean close. The camera check verifies pose and image changes after eight base steps. These real-simulator tests require a working GPU/EGL setup and are separate from offline CPU CI; skipped tests are not passes.

Troubleshooting

The asset root must contain downloaded collections and bundled scene, arena, and fixture files. Preserve attribution files. --skip-existing checks download inventories; for conflicting files, confirm that replacement is intended before using:

robocasa-download-assets --assets-path ~/.robocasa/assets --no-macros --overwrite -y

--overwrite takes precedence over --skip-existing and replaces only files in the installation scope. By default, conflicting files are preserved and the destination must support hard links. Allow space for ZIP archives and unpacked data, plus existing data during replacement. Rerun the download after an interruption.

Run the environment smoke tests first. After downloading all four resources, use the existing RoboCasa E2E component test to verify VLA worker startup, HTTP RPC and first inference. Install .[test] if needed, select one available GPU and use a fresh output directory:

CUDA_VISIBLE_DEVICES=0 \
RLDX_MODEL_PATH="$PWD/checkpoints/rldx-1-ft-rc365" \
RPENT_E2E_OUTPUT_DIR="$PWD/e2e-robocasa" \
HF_HUB_OFFLINE=1 TRANSFORMERS_OFFLINE=1 NO_ALBUMENTATIONS_UPDATE=1 \
MUJOCO_GL=egl python -m pytest -q \
   tests/e2e_tests/robocasa/test_components.py::test_rldx_component --timeout=300

These checks do not run a planner or create benchmark results. Skipped tests are not passes. Offline variables apply only to the check; ordinary HF memory sync needs network access. Keep remote planner proxies unchanged. The lightweight protocol tests still validate all 50 tasks and the fixed 340-cell denominator; full benchmark execution is a separate procedure.

• For slow package downloads, use UV_HTTP_TIMEOUT=600 and put caches and temporary files on a sufficiently large filesystem. Retry the pinned HF download; apparent shard size is not a completeness check. Do not disable TLS.

• A read-only asset failure needs the corrected RoboCasa dependency, not writable canonical assets. Transformed XML uses the temporary directory.

• For an RLDX offline cache miss, check the support snapshot and cache variables above. NO_ALBUMENTATIONS_UPDATE=1 disables only an import-time version check, not image processing. Keep the existing image-geometry fallback.

• Test the selected Torch/CUDA build with a GPU operation and EGL render, not just the driver’s version display. Use a build compatible with the host.

• For shared read-only installations, set NUMBA_CACHE_DIR to a writable per-user directory instead of making package code writable.

• If navigation RGB-D or world-map rendering reports a missing mobilebase0_navview, reinstall .[robocasa] to refresh the RLinf/robosuite rpent branch. Do not patch installed XML files manually.

• If read_text_file reports a missing current-task result, check the memory/robocasa/results/ corpus or the selected local directory. RPent does not fall back to another task’s memory. Markdown is optional; Atomic tasks have no published <Task>.md.

• Environment and VLA startup failures are recorded in <output_dir>/env_server.log and <output_dir>/vla_server.log; also inspect <output_dir>/run.log for the run-level error.

• Only the exact 127.0.0.1 and localhost hostnames bypass HTTP proxies automatically. Other hostnames and IPs use the standard proxy environment; add the exact host to NO_PROXY and no_proxy only when it should be reached directly.

Implementation Notes

The RoboCasa toolkit exposes the same shape of tools as LIBERO (a primitive call, a state view, a finish), with two RoboCasa-specific aspects:

• Env-side helpers. Grasp checks and action assembly need the live simulator env, so they live in env_server as RPCs. The agent-side skill holds both clients: the env client for render/step, the model client for RLDX-1 inference. See Add a Robot or Simulator for the rationale.

• Observation shape. RLDX-1 sees 3 camera video tensors (1, T, H, W, 3) stacked over history T, plus state.* and annotation.* fields. The session id is not part of the observation — it is managed automatically by the RPC framework: RpcClient generates a private rpc_ + uuid hex session id, wait_for_ready registers it with the server on connect; the server tracks each session’s idle time and a background sweep thread reaps sessions idle longer than the timeout (default 3600s), and the client sends session.close via atexit on process exit. Business code (rldx_skill / vla_client) never sees the session id directly; the server injects it into predict / reset_session to isolate per-client RLDX memory/RTC policy state.
